Ghost Lector FS SF Essential

Bike Geometry
Bottom bracket drop [mm]:
· 41 mm
· 33 mm
Chain stay length [mm]:
· 435 mm
· 440 mm
Fork total length [mm]:
0 mm
Head tube angle:
68 degrees
Head tube length [mm]:
· 90 mm
· 100 mm
· 120 mm
· 140 mm
Reach [mm]:
· 424 mm
· 453 mm
· 489 mm
· 507 mm
· 533 mm
Stack [mm]:
· 577 mm
· 575 mm
· 601 mm
· 618 mm
· 636 mm
Stand over height [mm]:
· 710 mm
· 730 mm
· 760 mm
· 770 mm
· 780 mm
Seat tube angle:
75.5 degrees
Seat tube length [mm]:
· 417 mm
· 441 mm
· 465 mm
· 489 mm
· 513 mm
Top tube length [mm]:
· 575 mm
· 603 mm
· 649 mm
· 669 mm
· 701 mm
Wheelbase [mm]:
· 1130 mm
· 1161 mm
· 1214 mm
· 1241 mm
· 1275 mm
Brake system
Brake Front Mount:
Post Mount
Brake Rear Mount:
Post Mount
Brake Front Description:
Formula, Hydraulische Scheibenbremse, Cura 2, 180 mm
Brake Rear Description:
Formula, Hydraulische Scheibenbremse, Cura 2, 180 mm
BrakeLever Description:
Formula, CURA 2-BL
Brake Rotor Description:
Formula, Cura 2 180 mm, 6 bolt Disc
Drivetrain
Cassette Teeth:
10-51T
Crankset Teeth:
32T
Crankset Type:
single
Number Of Gears:
12
Pedal Inclusive:
Nein
Bottom Bracket Description:
Shimano, BSA, BB-MT800
Cassette Description:
Shimano, Deore CS-M6100-12, MICRO SPLINE
Chain Description:
Shimano, Deore CN-M6100
Crankset Description:
Shimano, Deore FC-MT510
Derailleur Hanger Description:
Sram, UDH
Derailleur Rear Description:
Shimano, XT RD-M8100 12s
Gear Description:
Shimano, Derailleur
Shifter Right Description:
Shimano, Triggershift, Deore SL-M6100
Frame and more
Framesize Convection:
· L
Max loadable weight (KG):
120 kg
Front Fork Type:
Suspension
Suspension Type:
Fully
Travel Front:
· 100 mm
· 120 mm
Travel Rear:
· 100 mm
· 120 mm
Front Fork Description:
Fox Racing Shox, 34 A Float SC 29 Remote 100 mm
Frame Description:
LECTOR FS LC, Carbon, Uni
Shock Description:
Fox Racing Shox, Float SL P-Se Evol LV 100 mm
Handlebar and Saddle
Handlebar Diameter:
31.8 mm
Handlebar Material:
Aluminium
Handlebar Rise:
0
Handlebar Width:
· 700 mm
· 720 mm
· 740 mm
· 760 mm
Seatpost Material:
Carbon
Seatpost Travel (mm):
0 mm
Stem Length:
45 mm
Handgrip Description:
WTB, Trail II
Handlebar Description:
Ghost, Flat bar, Ground Fiftyone Dia. 31.8 mm
Headset Description:
Acros, Blocklock AZX-220-R4
Saddle Description:
Selle Italia, X3 Boost
Seatpost Description:
Ghost, Non Suspension, GND 51 Carbon Length: 450 mm, Dia. 34.9 mm, 450 mm
Stem Description:
Ghost, Ground Fiftyone Dia. 31.8 mm
Wheels and wheel components
Wheel Size:
29
Tyre Description:
Schwalbe, Racing Ralph Performance 2.25
Tyre Rear Description:
Schwalbe, Racing Ralph Performance 2.25
Wheelset Description:
Syntace, V30 15x110 mm
Wheelset Rear Description:
Syntace, V30 12x148 mm
Wheelsize Description:
29, 29
